2906 HAND-DRAWN CURTAIN TRACKS

  • • The ideal track for combining sheers and light or medium-weight curtains
  • • The track creates a perfect overlap between curtains
  • • You only have to mount one track to have three rail channels.
  • • Because of the low profile height of 8mm, the track is barely visible
  • • Concealed mounting on a ceiling or in a window opening gives a superbly elegant result.
  • • Compatible with the Goelst Flow System for regularly pleated curtains

The Goelst 2906 multichannel profile is the ideal track for combining sheers and (blackout) curtains. You only have to mount one track to have three rail channels. Because of the low profile height of 8mm, the track is barely visible. The track can be quickly and easily mounted on a ceiling or in a window opening.

Features
  • The ideal track for combining sheers and light or medium-weight curtains
  • Aluminium track; the 2909 cannot be bent
  • Concealed mounting on a ceiling or in a window opening
  • Suitable for mounting in window openings (tilt-and-turn windows)
  • Available as standard in white
  • Lengths: 4m and 6m
  • Compatible with the Goelst Flow System for regularly pleated curtains. More info about the Goelst Flow System
  • High-quality coated aluminium

The high-quality, carefully selected materials allow pleated curtains to run silently and smoothly.

Specifications
  • Material: aluminium
  • Coating colours: white RAL9010
    High quality wear-resistant, extremely colourfast, UV-resistant coating
  • Dimensions (hxw): 8 x 100mm
  • Profile weight: 741 gr/m
  • Maximum supported weight guideline: see fixing guide [link]. An additional support point is recommended at points where pleated curtains gather when open.
Bending

The 2906 cannot be bent. If a return curve is required, a separate 90 degree bend can be mounted on the track profile with the 2901-R-W. The separate bend is joined with connecting bridge 2952.

Standard components


Gliders
Twelve self-lubricating 2010 gliders per metre/track and 2 2001 end stops per track system

Fixing
Concealed ceiling mounting with 4.5 x 45mm screws with white caps 4514-WD

Accessories
2x end caps 2953-56
Tracks longer than the standard length can be joined together with connecting bridge 2952.




Optional components


Gliders
• 2010 gliders are available with various hook types.
• For perfectly closing curtains with an overlap of the curtain fabric, use pilot runner 4074-1000 or the smaller pilot runner 4075-1000.
• Track 2906 is compatible with the Goelst Flow system: gliders 2014-060 or 2014-080.
• The 2012 click glider can be placed anywhere in the system. It is advisable to place gliders of this type on the stacking side.


Fixing
• Concealed ceiling mounting with 4.5 x 45mm screws and white caps – custom-made profiles have pre-punched holes as standard.


Accessories
• Use the special glider stop for ‘spring-back’ curtain sets: fit the glider stop over a 2010 glider after it has been inserted in the channel profile. Several glider stops can be placed if necessary.
• Selection of various pull rods for opening and closing curtains by hand: usually used with curtains that are light in colour and show signs of wear more quickly and delicate curtain fabrics, such as sheers (in combination with lead gliders 4074-1000 or 4075-1000).


Material

Aluminium EN AW-6060 T66.
Shape and size tolerances in accordance with EN 12020.
Powder coating: in accordance with QUALICOAT requirements, thick coating (+/- 100 µm), AkzoNobel/Goelst quality for improved gliding properties and excellent ductility. White RAL 9010.
2906 track weight: 741 gr/m


Standard colours

White RAL 9010 – powder coated
Special colours available on request.


Standard accessories

Goelst self-lubricating, UV-resistant gliders made from high-quality plastic. Twenty-four 2010 gliders per metre, four 2001 end stops plus two 2953-56 end caps per track length.
Ceiling mounting with (4.5 x 45mm) screws with decorative cap 2914-WD (in profiles with pre-drilled holes) (the amount required depends on the system length). Connecting bridge 2952.


Other accessories and fixing

2010 gliders are available with various hook types. Metal end stop with eye 2001-50-M-N. Glider stop 2004. Pilot runner with overlap 4074-1000 or without overlap 4075-1000.
Suitable for Goelst Flow bespoke curtain systems.


Spacing between support points in accordance with the G-Standard or the table below.

gordijnsoort

licht

middel

zwaar

per pakket

2 kg

4 kg

8 kg

2906

100

80

60


General advice: place an additional bracket on the stacking side(s) and, if possible, a support point immediately before and/or after a curve.


Bending

Cannot be bent. A separate return bend can be by mounting a 2901-R-W.


Maintenance

General advice: impregnate with Goelst silicon spray (1251-250) at least 1x per year.


The Goelst 2906 multichannel profile is the ideal track for combining sheers and (blackout) curtains. You only have to mount one track to have three rail channels. Because of the low profile height of 8mm, the track is barely visible. The track can be quickly and easily mounted on a ceiling or in a window opening.

Features
  • The ideal track for combining sheers and light or medium-weight curtains
  • Aluminium track; the 2909 cannot be bent
  • Concealed mounting on a ceiling or in a window opening
  • Suitable for mounting in window openings (tilt-and-turn windows)
  • Available as standard in white
  • Lengths: 4m and 6m
  • Compatible with the Goelst Flow System for regularly pleated curtains. More info about the Goelst Flow System
  • High-quality coated aluminium

The high-quality, carefully selected materials allow pleated curtains to run silently and smoothly.

Specifications
  • Material: aluminium
  • Coating colours: white RAL9010
    High quality wear-resistant, extremely colourfast, UV-resistant coating
  • Dimensions (hxw): 8 x 100mm
  • Profile weight: 741 gr/m
  • Maximum supported weight guideline: see fixing guide [link]. An additional support point is recommended at points where pleated curtains gather when open.
Bending

The 2906 cannot be bent. If a return curve is required, a separate 90 degree bend can be mounted on the track profile with the 2901-R-W. The separate bend is joined with connecting bridge 2952.


The Goelst 2906 multichannel profile is the ideal track for combining sheers and (blackout) curtains. You only have to mount one track to have three rail channels. Because of the low profile height of 8mm, the track is barely visible. The track can be quickly and easily mounted on a ceiling or in a window opening.

Features
  • The ideal track for combining sheers and light or medium-weight curtains
  • Aluminium track; the 2909 cannot be bent
  • Concealed mounting on a ceiling or in a window opening
  • Suitable for mounting in window openings (tilt-and-turn windows)
  • Available as standard in white
  • Lengths: 4m and 6m
  • Compatible with the Goelst Flow System for regularly pleated curtains. More info about the Goelst Flow System
  • High-quality coated aluminium

The high-quality, carefully selected materials allow pleated curtains to run silently and smoothly.

Specifications
  • Material: aluminium
  • Coating colours: white RAL9010
    High quality wear-resistant, extremely colourfast, UV-resistant coating
  • Dimensions (hxw): 8 x 100mm
  • Profile weight: 741 gr/m
  • Maximum supported weight guideline: see fixing guide [link]. An additional support point is recommended at points where pleated curtains gather when open.
Bending

The 2906 cannot be bent. If a return curve is required, a separate 90 degree bend can be mounted on the track profile with the 2901-R-W. The separate bend is joined with connecting bridge 2952.

Advice and tips

  • • Advice: Drill an additional hole on the stacking side(s).
  • • Maintenance advice: for long-term optimal glider performance in every situation, we recommend using Goelst silicon spray 1251-250
  • • The front two tracks can be used to make pleated curtain systems close in the middle (see drawing for the correct method for mounting the rail and aligning the curtains).
  • • The lead gliders are strong and suitable for attaching to a pull rod. Using a pull rod to open and close the curtains keeps the fabric clean and prevents stains and signs of wear.
